Carte Mère Gigabyte Z390 AORUS ELITE ATX LGA1151 DDR4 USB3.1 M.2

Carte Mère Gigabyte Z390 AORUS ELITE ATX LGA1151 DDR4 USB3.1 M.2
zoom_out_map
chevron_left chevron_right
  • Supports 9th and 8th Gen Intel® Core™ Processors
  • Dual Channel Non-ECC Unbuffered DDR4, 4 DIMMs
  • Intel® Optane™ Memory Ready
  • 12+1 Phases Digital VRM Solution with DrMOS
  • Advanced Thermal Design with Screw Mounted Heatsinks
  • ALC1220-VB Enhance 114dB(Rear)/ 110dB(Front) SNR in Microphone with WIMA Audio Capacitors
  • Intel® Gigabit LAN with cFosSpeed
  • RGB FUSION with Multi-Zone LED Light Show Design, Supports Addressable LED & RGB LED Strips
  • Smart Fan 5 features Multiple Temperature Sensors and Hybrid Fan Headers with FAN STOP
  • Front USB 3.1 Gen 1 Type-C™ Header
  • Dual Ultra-Fast M.2 with PCIe Gen3 x4 interface
  • CEC 2019 Ready, Save Power With a Simple Click
170,99 €
En Stock

Les cartes-mères équipées d'un chipset Intel Série 300 (H310, B360, Z370, H370...) sont compatibles uniquement avec les processeurs Intel de 8ème et 9ème génération et par conséquence ne sont pas compatibles avec les processeurs Intel de 6ème et 7ème générationEn cas de doute n'hésitez pas à nous contacter pour nous demander conseil

DESCRIPTIF DÉTAILLÉ

  • Processeur
    1. Support for 9th and 8th Generation Intel® Core™ i9 processors/Intel® Core™ i7 processors/Intel® Core™ i5 processors/Intel® Core™ i3 processors/Intel® Pentium® processors/Intel® Celeron® processors in the LGA1151 package
    2. L3 cache varies with CPU
    (Please refer "CPU Support List" for more information.)
  • Chipset
    1. Intel® Z390 Express Chipset
  • Mémoire
    1. 4 x DDR4 DIMM sockets supporting up to 128GB (32GB single DIMM capacity) of system memory**
      ** Please note that the support for system total memory size depends on the CPU installed.
    2. Dual channel memory architecture
    3. Support for DDR4 4266(O.C.) / 4133(O.C.) / 4000(O.C.) / 3866(O.C.) / 3800(O.C.) / 3733(O.C.) / 3666(O.C.) / 3600(O.C.) / 3466(O.C.) / 3400(O.C.) / 3333(O.C.) / 3300(O.C.) / 3200(O.C.) / 3000(O.C.) / 2800(O.C.) / 2666 / 2400 / 2133 MHz memory modules
    4. Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode)
    5. Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
    6. Support for Extreme Memory Profile (XMP) memory modules
    (Please refer "Memory Support List" for more information.)
  • Carte Graphique Intégrée
    Integrated Graphics Processor-Intel® HD Graphics support:
    1. 1 x HDMI port, supporting a maximum resolution of 4096x2160@30 Hz
      * Support for HDMI 1.4 version and HDCP 2.2.
    Maximum shared memory of 1 GB
    Actual support may vary by CPU.
  • Audio
    1. Realtek® ALC1220-VB codec
      * The back panel line out jack supports DSD audio.
    2. High Definition Audio
    3. 2/4/5.1/7.1-channel
    4. Support for S/PDIF Out
  • Réseau
    1. Intel® GbE LAN chip (10/100/1000 Mbit)
  • Port d'expansion
    1. 1 x PCI Express x16 slot, running at x16 (PCIEX16)
      * For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot.
    2. 1 x PCI Express x16 slot, running at x4 (PCIEX4)
    3. 4 x PCI Express x1 slots
      * The PCIEX4 slot shares bandwidth with the PCIEX1_3 slot. When the PCIEX1_3 slot is populated, the PCIEX4 slot operates at up to x2 mode.
      (All of the PCI Express slots conform to PCI Express 3.0 standard.)
  • Technologie Multi-cartes graphiques
    1. Support for AMD Quad-GPU CrossFire™ and 2-Way AMD CrossFire™ technologies
  • Interface de Stockage
    Chipset:
    1. 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280/22110 SATA and PCIe x4/x2 SSD support) (M2A)
    2. 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280 SATA and PCIe x4/x2 SSD support) (M2M)
    3. 6 x SATA 6Gb/s connectors
    4. Support for RAID 0, RAID 1, RAID 5, and RAID 10
      * Refer to "1-7 Internal Connectors," for the installation notices for the M.2 and SATA connectors.
    Intel® Optane™ Memory Ready
  • USB
    Chipset:
    1. 2 x USB 3.1 Gen 2 Type-A ports (red) on the back panel
    2. 1 x USB Type-C™ port with USB 3.1 Gen 1 support, available through the internal USB header
    3. 6 x USB 3.1 Gen 1 ports (4 ports on the back panel, 2 ports available through the internal USB header)
    Chipset+2 USB 2.0 Hubs:
    1. 8 x USB 2.0/1.1 ports (4 ports on the back panel, 4 ports available through the internal USB headers)
  • Connecteurs d'entrées/sorties internes
    1. 1 x 24-pin ATX main power connector
    2. 1 x 8-pin ATX 12V power connector
    3. 1 x 4-pin ATX 12V power connector
    4. 2 x M.2 Socket 3 connectors
    5. 6 x SATA 6Gb/s connectors
    6. 1 x CPU fan header
    7. 1 x water cooling CPU fan header
    8. 3 x system fan/water cooling pump headers
    9. 2 x digital LED strip headers
    10. 2 x digital LED strip power select jumpers
    11. 2 x RGB LED strip headers
    12. 1 x front panel header
    13. 1 x front panel audio header
    14. 1 x USB Type-C™ port, with USB 3.1 Gen 1 support
    15. 1 x USB 3.1 Gen 1 header
    16. 2 x USB 2.0/1.1 headers
    17. 1 x S/PDIF Out header
    18. 1 x Trusted Platform Module (TPM) header (2x6 pin, for the GC-TPM2.0_S module only)
    19. 1 x Thunderbolt™ add-in card connector
    20. 1 x Clear CMOS jumper
  • Connecteur du Panneau Arrière
    1. 4 x USB 2.0/1.1 ports
    2. 1 x HDMI port
    3. 4 x USB 3.1 Gen 1 ports
    4. 2 x USB 3.1 Gen 2 Type-A ports (red)
    5. 1 x RJ-45 port
    6. 1 x optical S/PDIF Out connector
    7. 5 x audio jacks
  • Contrôleur d'Entrée/Sortie
    1. iTE® I/O Controller Chip
  • Monitorage Matériel
    1. Voltage detection
    2. Temperature detection
    3. Fan speed detection
    4. Water cooling flow rate detection
    5. Overheating warning
    6. Fan fail warning
    7. Fan speed control
      * Whether the fan (pump) speed control function is supported will depend on the fan (pump) you install.
  • BIOS
    1. 2 x 128 Mbit flash
    2. Use of licensed AMI UEFI BIOS
    3. Support for DualBIOS™
    4. PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
  • Fonctionnalités Exclusives
    1. Support for APP Center
      * Available applications in APP Center may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications.
      3D OSD
      @BIOS
      AutoGreen
      Cloud Station
      EasyTune
      Easy RAID
      Fast Boot
      Game Boost
      ON/OFF Charge
      Platform Power Management
      RGB Fusion
      Smart Backup
      Smart Keyboard
      Smart TimeLock
      Smart HUD
      Smart Survey
      System Information Viewer
      USB Blocker
      V-Tuner
    2. Support for Q-Flash
    3. Support for Xpress Install
  • Logiciels Fournis
    1. Norton® Internet Security (OEM version)
    2. cFosSpeed
  • Système d'Exploitation
    1. Support for Windows 10 64-bit
  • Dimensions
    1. ATX Form Factor; 30.5cm x 24.4cm
  • Remarque
    1. Due to different Linux support condition provided by chipset vendors, please download Linux driver from chipset vendors' website or 3rd party website.
    2. Most hardware/software vendors may no longer offer drivers to support Win9X/ME/2000/XP. If drivers are available from the vendors, we will update them on the GIGABYTE website.

Pour plus d'informations, vous pouvez consulter la page du produit sur le site du constructeur, disponible ICI

Fiche technique
Référence Fabricant
Z390 AORUS ELITE
Format Carte Mère
ATX
Chipset Carte Mère
Intel Z390
Socket CPU
Intel 1151
Fréquence Mémoire supportée
4266 Mhz
Type de Mémoire
DDR4 (DIMM 288 pins)
Garantie Constructeur (Mois)
36
